Hi Xiangdong,

Below are the equations you sent us last week. I corrected them from the second email you sent. Can you verify that the equations and component definitions are correct? I made the equations in LaTeX so they have the correct formatting so if you can't see them or something, please let me know and I can resend them.

[cid:e8fb2899-fbd8-45fa-befc-bfd4145f8bae]

I also have some questions on what you're requesting:

  1.  Do you want to completely remove the acquisition of X and Y from the fsNMR program when scaling and replace it with calculated X and Y using the formulas?
  2.  If #1 is correct, shouldn't the non-scaled data acquisition also be changed to calculate X and Y rather than acquiring it from the lock-in amplifier?

-Tyler
