Sharing good news:

1) the Pressure tests of the Solenoid Magnet shield piping was completed this morning at 320psig.
2) the final leak tests were done by
a) bagging fitting on the end of each tube
b) filling the bags and waiting 1-3 minutes depending on which end we were pumping on
c) spraying helium into the IV a couple times to confirm no internal leaks.

We we had background levels in the magnet of 1 to 2 to E-9 torr*liter/sec on each of the tests.

See photos.

We repeated the flow test of the BL side just to confirm blockage during repair (see attached file)(no significant change ... measurement error difference)

Also today we have welded more of the magnet primary helium circuit and started purging and fit up of the Magnet Reservoir (MR) differential pressure level transducer (high pressure side) tube coupling.

Also Probir/Ruben and Renuka took advantage of breaks in the action to make more electrical measurements AND the survey team was back to take some data that they said had some issues from yesterday.

Dave


----- Original Message -----
From: "kashy" <kashy at jlab.org>
To: "Ruben Fair" <rfair at jlab.org>, "Glenn Young" <gyoung at jlab.org>, "Volker Burkert" <burkert at jlab.org>, "hallb-engineering" <hallb-engineering at jlab.org>, "Hogan" <hogan at jlab.org>, "Joseph Matalevich" <josephm at jlab.org>, "Brian Eng" <beng at jlab.org>, "Pablo Campero" <campero at jlab.org>, "carstens" <carstens at jlab.org>, "rossi patrizia" <rossi at jlab.org>
Sent: Wednesday, July 12, 2017 7:53:06 AM
Subject: Solenoid Status Update

Highlights

Monday:
Day shift fit up the MR return piping and tacked it in.
Second shift
1) found a 1E-6 leak on the BL shield circuit at the connection between the rectangular tube and the bi-braze connection.
2) Fully welded out the MR 4K return line

Tuesday:
Day shift
1) Pin pointed two leaks with snoop and made repair plan with Mike Martin included
2) Completed flow tests of BL and BR flow tubes and as hoped they are about the same so the temperature of the shields should be similar both left and right side (see attached file)
3) Continued welding on 4K Reservoir piping
4) Did studies on Z supports
5) Survey group took data on SST to Magnet and magnet bottom plate to save time with SST clamshell triming and fitup

Second shift
1) repair of the leaks in the aluminum weld
2) full repeat of the cold shock with better N2 reservoirs to assure better cooling
3) leak test of the repair (successful with NDL at 1E-9)

Today:
Day shift plan
1) Pressure test Magnet shield circuits again to 320psig
2) Final leak test of Magnet shield circuits
3) Final flow test of repaired shield circuit
4) Analysis of the Z support
5) Welding of the MR 1/2" and 1/4" OD tubing
6) More electrical tests this evening ( not to disturb welding progress per RF)

Second Shift:
1) Fitting and welding of Magnet shield circuit piping to SST shield piping
2) Vaporizer leak testing and transport to Hall B?
-------------- next part --------------
A non-text attachment was scrubbed...
Name: IMG_5282 BR shield test.JPG
Type: image/jpeg
Size: 2119926 bytes
Desc: not available
URL: <https://mailman.jlab.org/pipermail/hallb-engineering/attachments/20170712/2ea5a175/attachment-0012.jpe>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: IMG_5285 bags on BL fittings.JPG
Type: image/jpeg
Size: 1462353 bytes
Desc: not available
URL: <https://mailman.jlab.org/pipermail/hallb-engineering/attachments/20170712/2ea5a175/attachment-0013.jpe>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: IMG_5286 - full bag on BR fitting.JPG
Type: image/jpeg
Size: 1414346 bytes
Desc: not available
URL: <https://mailman.jlab.org/pipermail/hallb-engineering/attachments/20170712/2ea5a175/attachment-0014.jpe>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: IMG_5288 Full bag on BR fitting.JPG
