Hi Allen,

Tiffany has updated the C100R WCD register, and the email names in WCD-R5 should reflect what we want on this traveler (C100R-INSP-FPFT-R2).

>From the draft you edited on July 8, just make sure the email names are the same as in WCD-R5. The drawings you added can be kept as-is.

Thanks,
Liang
________________________________
From: Allen Samuels <samuels at jlab.org>
Sent: Thursday, July 11, 2024 3:07 PM
To: Liang Zhao <lzhao at jlab.org>
Cc: pansophy <pansophy at jlab.org>; Tiffany Ganey <ganey at jlab.org>
Subject: RE: C100R FPFT inspection traveler updated drafts for approval

Liang and Tiffany,

Apologies for not keeping on top of this conversation, I was working on other projects and wasn’t paying close attention. The changes I made to the NCR/D3 emails and approvals were made so that the traveler reflects what is listed in the C100R Work Control Document. If that is in error, we’ll need to update both this traveler and it.

As for the drawings, if you’d prefer to use the link you sent earlier (https://misportal.jlab.org/reqs/prs/429457#ShowGeneralTab), I can remove the drawings for now and put that in instead.

Allen

From: Liang Zhao <lzhao at jlab.org>
Sent: Thursday, July 11, 2024 1:40 PM
To: Allen Samuels <samuels at jlab.org>
Cc: pansophy <pansophy at jlab.org>; Tiffany Ganey <ganey at jlab.org>
Subject: Re: C100R FPFT inspection traveler updated drafts for approval

Hi Allen,

I just disapproved this draft, assuming you will make the changes to the email names according to Tiffany's suggestions.

I think the other changes you made in this draft are good to go.

Thanks,

Liang

________________________________

From: Liang Zhao <lzhao at jlab.org<mailto:lzhao at jlab.org>>
Sent: Tuesday, July 9, 2024 4:15 PM
To: Tiffany Ganey <ganey at jlab.org<mailto:ganey at jlab.org>>; Allen Samuels <samuels at jlab.org<mailto:samuels at jlab.org>>
Cc: pansophy <pansophy at jlab.org<mailto:pansophy at jlab.org>>
Subject: Re: C100R FPFT inspection traveler updated drafts for approval

Thanks for the input, Tiffany.

I will start a conversation with Jim about updating the drawings, copying you. It would help if you can outline to Jim where in the drawing needs to be updated based on what has been changed from the original drawing, or what in the original drawing needs to be removed. Maybe you have already started the conversation with him, and I can follow up with him if that is the case.

As for when to put in an updated drawing, I am thinking leaving the current traveler draft as is for now, until we are getting closer to have these new probes in a cryomodule. Hopefully we will have an updated drawing later on and I will do a revision of this traveler then with the drawing.

For now, if desired, we can have a link of the PR (https://misportal.jlab.org/reqs/prs/429457#ShowGeneralTab) in the Reference box of the traveler, if Pansophy and the project think it is acceptable. Or just use what Allen has put in for now, which is the original CRM1007014-0009 (field probe tip) and CRM1007014-0010 (field probe assembly).

Liang

________________________________

From: Tiffany Ganey <ganey at jlab.org<mailto:ganey at jlab.org>>
Sent: Tuesday, July 9, 2024 3:02 PM
To: Liang Zhao <lzhao at jlab.org<mailto:lzhao at jlab.org>>; Allen Samuels <samuels at jlab.org<mailto:samuels at jlab.org>>
Cc: pansophy <pansophy at jlab.org<mailto:pansophy at jlab.org>>
Subject: RE: C100R FPFT inspection traveler updated drafts for approval

I agree that Danny would be a better Dispositioner than Anne. But I think we are generally trying to have the WCL as a potential dispositioner.  So I suggest the following:

NCR informative: areilly,overtonr,georged,mosby

NCR dispositioner: lzhao,forehand,mcewen,ganey

The changes to this part have not been incorporated into an official drawing revision yet, so the marked up version is the closest we have now to what should be used for the inspection.  Liang- you may want to work with Jim to get a revised drawing in document control for the new part dimensions, especially if we end up using these probes on final assembly for cryomodules.

Tiffany Ganey

From: Liang Zhao <lzhao at jlab.org<mailto:lzhao at jlab.org>>
Sent: Tuesday, July 9, 2024 1:55 PM
To: Allen Samuels <samuels at jlab.org<mailto:samuels at jlab.org>>
Cc: pansophy <pansophy at jlab.org<mailto:pansophy at jlab.org>>; Tiffany Ganey <ganey at jlab.org<mailto:ganey at jlab.org>>
Subject: Re: C100R FPFT inspection traveler updated drafts for approval

Hi Allen,

I have some comments on the draft that you edited:

I don't think it is necessary to put Anne's name on the NCR dispositioner. Instead it makes sense to have Danny be one of the dispositioner as he is heavily involved in choosing and using the field probe. So I suggest the email names be:

NCR informative: areilly,overtonr,georged,mosby

NCR dispositioner: lzhao,forehand,ganey

D3 emails: areilly,overtonr,lzhao,forehand,ganey,georged,mosby

About the drawing:

The drawing with blue rectangles shows the the incoming ordered probes are still based on the CRM-100-7014-0010 drawing, but it masks up some outdated information not needed for inspection of this coming purchase order.

If the mod drawing link does not work under current rules, I wonder is it possible to put a link of the PR int he reference instead to reflect the changes made in purchasing these field probes.

The other changes  you made look good to me.

Tiffany may have her opinion on the above comments. I'd like to hear what she thinks as well.

Thanks,

Liang

________________________________

From: Allen Samuels <samuels at jlab.org<mailto:samuels at jlab.org>>
Sent: Monday, July 8, 2024 3:33 PM
To: Liang Zhao <lzhao at jlab.org<mailto:lzhao at jlab.org>>
Cc: pansophy <pansophy at jlab.org<mailto:pansophy at jlab.org>>; Tiffany Ganey <ganey at jlab.org<mailto:ganey at jlab.org>>
Subject: RE: C100R FPFT inspection traveler updated drafts for approval

Thank you Liang. I’m looking over them right now.

Just a heads up going forward, drawings should link to their versions in the jlab docs repository<https://misportal.jlab.org/jlabDocs/nodes/127/search>, not docushare anymore. I’m working on updating the links on these for you so you don’t have to worry about the links for these, just use it for future travelers and revisions (use the file upload link on the document listing. It won’t work if you click it in word, but it will in pansophy).

One question I did have about the drawings, I’m working on C100R-INSP-FPFT-R2 and I noticed that your version has blue rectangles covering up parts of the drawing, while the doc repository version does not. Do these measurements need to remain redacted? I’ll update with the assumption that it’s fine, but if it’s not we’ll have to figure something out. For context, see the images below

[cid:image001.png at 01DAD3A1.D60AD340]

[cid:image002.png at 01DAD3A1.D60AD340]

Allen

From: Liang Zhao <lzhao at jlab.org<mailto:lzhao at jlab.org>>
Sent: Monday, July 8, 2024 2:23 PM
To: Allen Samuels <samuels at jlab.org<mailto:samuels at jlab.org>>
Cc: pansophy <pansophy at jlab.org<mailto:pansophy at jlab.org>>; Tiffany Ganey <ganey at jlab.org<mailto:ganey at jlab.org>>
Subject: C100R FPFT inspection traveler updated drafts for approval

Hi Allen,

I put three travelers in the ready for approval folder for C100R:

C100R-INSP-FPFT-R2

C100R-CMA-FPFT-LEAK-R1

C100R-VTA-FPFT-CSHK-R1

Could you help with getting them into Pansophy?

Thanks,

Liang
