Hi Amanda,

The thermal images of the heated parts on the PCB behind IGH front panel are attached here. Except the full panel view, temperature of all related parts (R401, R402 and D401') were displayed on the center, while the date and time were shown on the upper right corner.

Thanks,

Xiangdong
