Mike,

Will this work for you now???

Valerie

From: John Fischer <fischer at jlab.org>
Sent: Friday, October 23, 2020 10:34 AM
To: Valerie Bookwalter <bookwalt at jlab.org>
Subject: RE: C75 Traveler Acronym question C75-CMA-RECBP-ASSY-R1

Valerie,
I will try.  RECBP (Return End Can Beam Pipe Assy) is the same thing as the Return Side Warm Beam Tube. The acronyms were created by us and the dwg was created 30 years ago, no surprise the naming is different.
I think RWRK would be fine. The actual installation of it onto a Cryomodule is covered somewhere else. But this also means more of the beampipe travelers should be renamed.
JF



From: Valerie Bookwalter <bookwalt at jlab.org<mailto:bookwalt at jlab.org>>
Sent: Friday, October 23, 2020 10:01 AM
To: John Fischer <fischer at jlab.org<mailto:fischer at jlab.org>>
Cc: Chris Wilcox <wilcox at jlab.org<mailto:wilcox at jlab.org>>; E. Anne McEwen <mcewen at jlab.org<mailto:mcewen at jlab.org>>; pansophy <pansophy at jlab.org<mailto:pansophy at jlab.org>>
Subject: FW: C75 Traveler Acronym question C75-CMA-RECBP-ASSY-R1

John,

Can you answer these questions so we can finish processing this traveler?

Valerie
Pansophy Team

From: Valerie Bookwalter
Sent: Thursday, October 22, 2020 12:04 PM
To: Chris Wilcox <wilcox at JLAB.ORG<mailto:wilcox at JLAB.ORG>>
Cc: John Fischer <fischer at jlab.org<mailto:fischer at jlab.org>>; Kenneth Worland <worland at jlab.org<mailto:worland at jlab.org>>; Kurt Macha <macha at jlab.org<mailto:macha at jlab.org>>; pansophy <pansophy at jlab.org<mailto:pansophy at jlab.org>>
Subject: C75 Traveler Acronym question C75-CMA-RECBP-ASSY-R1

Chris,

The acronym RECBP, refers to the Return End Can Beam Pipe.
RTBP - is the Return Beam Pipe.
The drawing linked in the traveler is below and refers to Return Side Warm Beam Tube.

[cid:image001.png at 01D6A926.E0095E10]
Can someone confirm which "beam pipe" this is?
Additionally, this traveler is both Disassembly and Re-assembly, so should this be a RWRK (rework) instead of an assembly (ASSY).
The traveler can be found in the Drafts Folder in the C75 docushare folder or the link below.

https://jlabdoc.jlab.org/docushare/dsweb/Get/Document-226413/C75-CMA-RECBP-ASSY-R1.docxc

Thank You.

Valerie Bookwalter
Pansophy Team
