[Dsg-halla_ecal] 24V 70W cartridge heaters

Donald Jones jonesdc at jlab.org
Wed Mar 8 09:55:20 EST 2023


Hi Albert,
If you are worried about the wire temperature, then purchase a few of these from Grainger for testing. https://www.grainger.com/product/TEMPCO-Swaged-Cartridge-Heater-100-4NJA4. You will then have to modify the heater aluminum plate as shown below to accommodate the larger size. You should also purchase some ceramic wire nuts (https://www.grainger.com/product/TEMPCO-Ceramic-Wire-Connector-White-36D140) or something similar for connecting the heaters. I already have high heater fiberglass electrical tape.
-Don

[cid:33279357-fb24-449e-a808-b365d1ebca71]

Donald Jones
Hall A/C Staff Scientist
Jefferson Lab
Newport News, VA
________________________________
From: Dsg-halla_ecal <dsg-halla_ecal-bounces at jlab.org> on behalf of shahinya--- via Dsg-halla_ecal <dsg-halla_ecal at jlab.org>
Sent: Wednesday, March 8, 2023 8:48 AM
To: Marc Mcmullen <mcmullen at jlab.org>
Cc: dsg-halla_ecal at jlab.org <dsg-halla_ecal at jlab.org>
Subject: Re: [Dsg-halla_ecal] 24V 70W cartridge heaters

Hi Marc,

I've looked at the heater's data sheet and can't find
any details on what temperature can operated  wires?
Please let me know about wire temperature?

Thank you,
Albert


> Hi Jack,
>
> I gave Albert 18  cartridge heaters  this morning (EEL room 122). The
> specifications for the heaters can be found at the link below. I kept a
> few heater to do some testing with controls development.
>
> I'll schedule a meeting after I have some data to present from a controls
> stand point.
>
> Marc
>
> https://www.amazon.com/gp/product/B09VNYCNRJ?ref=ppx_pt2_dt_b_prod_image&th=1
> _______________________________________________
> Dsg-halla_ecal mailing list
> Dsg-halla_ecal at jlab.org
> https://mailman.jlab.org/mailman/listinfo/dsg-halla_ecal
>
